PRODUKT JIŽ NENÍ URČEN K PRODEJI
Detail
pecifications:
. CPU type:
VIA V4 Eden / ULV or C7 Nano-BGA2 400 pin L1 128 KB,
L2 128 KB on die
. Front Side Bus:
400/533 MHz
. MB Chipset:
VIA CN700 + VT8237R Plus
. Graphics:
Integrated with VIA CN700
Shared system memory up to 64MB
. Memory:
1 x DDRII SDRAM (max. 1GB)
. IDE:
Ultra DMA-133 / 100 / 66, 1 x 40 pin 2.54mm, 1 x 44 pin 2.0mm
CF Card Type II for ATA interface
. SATA:
1 x SATA port
. Audio:
AC-Link for Audio CODEC, AC’97 2.1
. LAN:
3 x Realtek 10 / 100 Mbps (optional Realtek / Intel Gigabit)
Intel 82541PI or Realtek RLT8100C / RLT8110SC LAN Chip
. IO function:
2 x RS232
Supports Infrared SIR & FIR
Supports one printer port
. USB:
7 x USB 2.0 (3 external + 4 internal)
. TV-Out (Option):
Supports all NTSC & PAL formats. Resolution : 1024 x 768
. WDT (option):
Hardware Watch Dog Timer, 0~255 sec programmable
. Expand interface:
1 x Mini PCI socket
. Power:
On board DC +12V ± 5% convert to +3.3V / +5V / +12V for system
. Dimension:
200 x 150 mm
. Operation Temp.:
0 ~ 60°C
. Operation Humidity:
5~95% @ 60°C, non-condensing
Testing environment:
Model name :
CV700A-3R10C
CPU :
VIA Eden ULV 1 GHz
Chipset :
VIA CN700 & VIA VT8237R PLUS
OS :
WIN XP
Testing Program :
3D Mark 2001 SE
. CPU type:
VIA V4 Eden / ULV or C7 Nano-BGA2 400 pin L1 128 KB,
L2 128 KB on die
. Front Side Bus:
400/533 MHz
. MB Chipset:
VIA CN700 + VT8237R Plus
. Graphics:
Integrated with VIA CN700
Shared system memory up to 64MB
. Memory:
1 x DDRII SDRAM (max. 1GB)
. IDE:
Ultra DMA-133 / 100 / 66, 1 x 40 pin 2.54mm, 1 x 44 pin 2.0mm
CF Card Type II for ATA interface
. SATA:
1 x SATA port
. Audio:
AC-Link for Audio CODEC, AC’97 2.1
. LAN:
3 x Realtek 10 / 100 Mbps (optional Realtek / Intel Gigabit)
Intel 82541PI or Realtek RLT8100C / RLT8110SC LAN Chip
. IO function:
2 x RS232
Supports Infrared SIR & FIR
Supports one printer port
. USB:
7 x USB 2.0 (3 external + 4 internal)
. TV-Out (Option):
Supports all NTSC & PAL formats. Resolution : 1024 x 768
. WDT (option):
Hardware Watch Dog Timer, 0~255 sec programmable
. Expand interface:
1 x Mini PCI socket
. Power:
On board DC +12V ± 5% convert to +3.3V / +5V / +12V for system
. Dimension:
200 x 150 mm
. Operation Temp.:
0 ~ 60°C
. Operation Humidity:
5~95% @ 60°C, non-condensing
Testing environment:
Model name :
CV700A-3R10C
CPU :
VIA Eden ULV 1 GHz
Chipset :
VIA CN700 & VIA VT8237R PLUS
OS :
WIN XP
Testing Program :
3D Mark 2001 SE
