Ultra Small Form Factor PC

Emcon and SST TEMPEST Ultra Small Form Factor PC

Petr Chalupa

Petr Chalupa

Odolné PC, Military, TEMPEST, Doprava +420 251 614 073

Základní informace

The Ultra Small Form Factor PC has the performance of a desktop system in a compact size. With an I7 processor; removable drives, and dual DVI video, it addresses the common needs of the Secure Office with extreme flexibility.

It can be used as a desktop PC (smaller than Thin Clients) or mounted to an LCD for a “zero footprint” configuration or “All in One.” Using 90% less energy than traditional systems, the Ultra Small Form Factor is also a green TEMPEST solution for the modern office.

This device is certified to NSTISSAM TEMPEST/1-92, Level I; CID09/15A, Level I; and SDIP-27/2. Level A (providing the equipment and associated systems are installed to the requirements identified in SDIP-29).

The Secure Systems and Information Assurance division of API Technologies offers global support. Below you will find links to North American and European office locations which offer TEMPEST product and service support.


 Pro konkrétní konfiguraci kontaktujte našeho projektového manažera.

Vzorová konfigurace:

Processor 5th Generation, Intel®i7-5557u processor (3.1ghz up to 3,4 GHz, Turbo Dual Core, 4 MB cache, 28W TDP
Graphics Intel Iris graphics 6100
Memory 16GB DDR3 1600MHz RAM
Storage Up to 2x Removable Drives
240 Gig SSD (other sizes available)
Display Sunlight readable 14” widescreen; 800NITs
Interfaces Video:2x DVI-D
USB Mouse: 1x DB9
USB Keyboard: 1x DB9
Network Interface: ST or SC
OS Win7 PRO available
Network 100FX or 1000SX Fiber
Input Devices Keyboard: USB US English (915-KYB1-0016)
Mouse: USB 3-Button (915-MOU1-0005)
Power Auto-Switching 65W, 90-230VAC
Dimensions and Weight (configuration dependent) Height 27.08 cm (10.6")
Width 19 cm (7.4")
Depth 8.5 cm (3.4")
Security Features Locking door
Removable hard drive caddy
Environment Specifications Operating: 0° to 50°C/32° to 120°F
Warranty 1 year, return to depot, parts and labour
Security Accreditations TEMPEST Level I - This device meets the requirements of: NSTISSAM TEMPEST/1-92, Level I; CID09/15A
