SR800-SP
Military 2U 19"/2 server s procesorem Intel Xeon-SP 5.generace a podporou VMware ESXi 8
Popis
- Military 2U Half-Rack GPU Server
- VMware vSphere ESXi 8 Support
- 5th Intel Emerald Rapids Xeon-SP Processor
- NVIDIA RTX A6000 Ada Support
- 2 x U.2 NVMe, 1 x M.2 NVMe
- MIL-STD-810 Vibration Method 514.6: ◎Acceleration : 5.0 Grms
- MIL-STD-810 Vibration Method 514.6: ◎PSD : 0.01257 g2/Hz
- MIL-STD-810 Shock Method 516.6 : ◎Wave Form: Half Shine Wave
- MIL-STD-810 Shock Method 516.6 : ◎Acceleration: 20G
- MIL-STD-461 EMI DC-IN 18V~36V (Options)
- Extended Temperature -20~+55°C
Specifikace
| CPU | Intel® Xeon® Platinum 8468 Processor, 48C, 105M Cache, 2.10 GHz, 350W Intel® Xeon® Gold 6443N Processor, 32C, 60M Cache, 1.90 GHz, 195W Intel® Xeon® Gold 6430 Processor, 32C, 60M Cache, 2.10 GHz, 270W Intel® Xeon® Silver 4416+ Processor, 20C, 37.5M Cache, 2.00 GHz, 165W Intel® Xeon® Platinum 8580 Processor, 60C, 300M Cache, 2.00 GHz, 350W Intel® Xeon® Gold 6554S Processor, 36C, 180M Cache, 2.20 GHz, 270W Intel® Xeon® Gold 6538N Processor, 32C, 60M Cache, 2.10 GHz, 205W Intel® Xeon® Gold 5512U Processor, 28C, 52.5M Cache, 2.10 GHz, 185W Intel® Xeon® Silver 4516Y+ Processor, 24C, 45M Cache, 2.20 GHz, 185W |
| Memory type | 4th Gen. Up to 4TB ECC L/RDIMM, DDR5-4400/4000MHz 5th Gen. Up to 4TB ECC L/RDIMM, DDR5-5600/5200/4800/4400MHz |
| GPU | Quadro RTX A6000 GPU Card Quadro MXM A4500 GPU Module |
| Storage | 2 x U.2 NVMe 1 x M.2 NVMe |
| Ethernet | 4 x 10GbE LAN |
| Front I/O | Power In: 1 x DC-IN COM: 1 x COM IPMI: 1 x IPMI LAN USB: 2 x USB 3.2 Gen1 + 2x USB2.0 LAN: 2 x 10GbE LAN Display: 1 x VGA |
| Expansion I/O | Ethernet 4x 10GbE LAN GPU 1x PCIe slot for NVIDIA A6000 or A100 |
| Weight | 16 KG |
| Operating Temp. | -20°C to 55°C |
| Storage Temp. | -40°C to 85°C |
| Relative Humidity | 5% to 95%, non-condensing |
