PN-V551

Sharp PN-V551 představuje 55" Full HD profesionální LCD displej s ultra tenkým rámečkem (3,5 mm), který umožní flexibilně sestavit videostěny prakticky do jakékoliv komerčního či veřejného prostoru. Displej je zodolněný pro nepřetržitý provoz.

PRODUKT JIŽ NENÍ URČEN K PRODEJI

Specifikace

Model PN-V551
Installation Landscape / Portrait
LCD Panel   55-inch widescreen (138.8 cm diagonal) TFT LCD
Max. Resolution 1,920 x 1,080 pixels
Max. Display Colours (approx.) 16.77 million colours
Pixel Pitch (H x V) 0.63 x 0.63 mm
Brightness*1 700 cd/m2 (default: 550 cd/m2)
Contrast Ratio*1 3,500 : 1
Viewing Angle (H/V) 178°/178° (CR ≥ 10)
Active Screen Area 1,209.6 x 680.4 mm (47 5/8" x 26 13/16")
(W x H)
Response Time 8 ms (grey to grey, avg.)
Backlight LED, full array
Computer Input Video Analogue RGB (0.7 Vp-p) [75 Ω], Digital (conforms to DVI 1.0 standards), DisplayPort 1.1a
Synchronisation Horizontal/vertical separation (TTL: positive/negative), Sync-on-green*2, Composite sync*2 (TTL: positive/negative)
Plug & Play VESA DDC2B
Power Management VESA DPMS, DVI DMPM
Video Colour System NTSC (3.58 MHz, 4.43 MHz), PAL, PAL60, SECAM
Input Terminals*3 HDMI™*4 x 1, Mini D-sub 15-pin x 1*5, video x 1*5, Component video x 1*5, DisplayPort x 1, DVI-I-29 pin (HDCP compatible) x 1, 3.5 mm-diameter mini stereo jack x 1, RS-232C x 1, D-sub 9-pin x 1, Control kit terminal x 1
Output Terminals*3 DisplayPort*6 x 1, DVI-D 24-pin (HDCP compatible) x 1, 3.5 mm-diameter mini stereo jack x 1, RS-232C x 1, D-sub 9-pin x 1
Input/Output Terminals*3 LAN port
Mounting VESA (4 points), 400 mm (15 3/4") pitch
Power Supply 100V — 240V AC, 50/60 Hz
Power Consumption 210 W
Environmental Operating Temperature 0°C to 40°C
Conditions Operating Humidity 20% to 80% RH (no condensation)
Dimensions*7 (W x D x H) (approx.) 1,213.5 x 113.8 x 684.3 mm (47 3/4" x 4 1/2" x 26 15/16")
Weight (approx.) 27.5 kg (60.2 lbs)
Main Accessories Cable clamp x 4, cable clamp (insertion type) x 2, power cord x 1, CD-ROM x 1, set-up manual x 1, remote control sensor box mounting hole concealing sticker x 2

*1 Brightness and contrast ratio depend on input mode and other picture settings. Brightness level will decrease slightly over the lifetime of the product. Due to the physical limitations of the equipment, it is not possible to maintain a precisely constant level of brightness.
*2 D-sub input terminal only.
*3 Use a commercially available connection cable for PC and other video connections.
*4 For both PC and AV components.
*5 Analogue PC, video, and component video are switchable (via the bottom interface); use the menu to select. Note that video and component video inputs require a conversion cable connected via the mini D-sub 15-pin jack.
*6 For video signals only.
*7 Display only, not including protrusions.
