PRODUKT JIŽ NENÍ URČEN K PRODEJI
Specifikace
Model Name
|
OLS-4650NP(TP) | ||||
Panel | Bezel | 17.6mm | |||
Resolution (H x V) | 1920 x 1080(16:9) | ||||
Pixel Pitch (H x V mm) | 0.53025 x 0.53025 | ||||
Display Colors | 16.7M(8bit) | ||||
Luminance of White(Typ.) | 700 cd / m2 | ||||
Contrast ratio (Typ.) | 4,000 : 1 | ||||
Repose Time (Typ.) | 8msec | ||||
Viewing Angle(U/D/R/L) | 89/89/89/89 | ||||
Surface Treatment | Haze 44%, Anti-Glare, Hard-Coating(3H) | ||||
Operating Life Time (Typ.) | Typ. 50,000Hrs | ||||
Power Supply | AC100V ~ 240V±10% (50/60Hz) | ||||
Power | Max. | 170W | |||
Consumption | Typ. | 165W | |||
Stand-By | ≤ 0.5W | ||||
OSD Language | English / Spanish / Portuguese / German / French / Italian / Chinese / Japanese | ||||
Special Function | Auto Brightness, Temperature Sensor, Smart Schedule, Power Save, Video-Wall, Button Lock | ||||
Input Video Signal | Signal | VGA, SVGA, XGA, SXGA, UXGA, WXGA, 480p,576p,720p(50/60),1080i(50/60),1080p(50/60) | |||
Frequency | H : 31.5 ~ 75kHz, V : 50 , 60 Hz | ||||
In/Output Video | DVI (DVI-D) | 1.1 | |||
Terminal | PC (D-SUB 15Pin) | 1/0 | |||
HDMI (1.3) | 2/0 | ||||
Display Port (1.2) | 1/0 | ||||
In/Out Audio | Speaker | 7W + 7W | |||
Terminal | DVI IN | O | |||
PC IN | O | ||||
Control | RS-232 (D-SUB 9Pin) | 1.1 | |||
Ethernet (RJ45) | O | ||||
IR Remote Control | O | ||||
Key-Pad | O | ||||
Installation Format | Landscape/Portrait | ||||
VESA Mount | 600 x 400 | ||||
Diemnsion(W x H x D mm) | 1051.6 * 604.8 * 67.5 | ||||
Net Weight (Kg) | 23.5Kg ± 0.5Kg |
