A12B MPC8245 CPU Board (M-Modules)

A12B - 6U VMEbus MPC8245 CPU Board (M-Modules™) - PowerPC® MPC8245 / 300 MHz - VMEbus master and slave - 512 MB DRAM, CompactFlash® - Dual 10/100-Mbit Fast Ethernet - 4 COMs, USB, IDE, keyboard/mouse - 3 M-Module™ slots - MENMON™ BIOS for PowerPC® cards

Petr Chalupa

Petr Chalupa

Odolné PC, Military, TEMPEST, Doprava +420 251 614 073


al UARTs, a CAN bus interface, DSP functions etc. In addition, the A12B CPU board can be equipped with M-Module™ mezzanine cards. M-Modules™ are recommended for real-world I/O like analog/binary process I/O and instrumentation I/O. The modular combination of I/O functionality on a single-board computer allows to build up tailored control systems which appear as customized solutions based on standard components. The A12 comes with MENMON™ support. This firmware/BIOS can be used for bootstrapping operating systems (from disk, flash or network), for hardware testing, or for debugging applications without running any operating system. The A12 single-board computer is partly compatible with the MVME2100 board by Motorola.
