RC5
LED displej určený pro rental aplikace nabízí rozteč bodů 5.0 mm a rozměr panelu 488 × 488 mm.
PRODUKT JIŽ NENÍ URČEN K PRODEJI
Základní informace
High resolution and pixel density
Quick and convenient installation
Noise-free effect
High flatness and seamless matching
Uniform color and high contrast ratio
High stability and reliability
Specifikace
| Item | Value |
| Pixel Pitch(mm) | 3.8 |
| Pixel Density(pixels/㎡) | 68889 |
| Pixel Configuration | SMD 1R1G1B |
| Viewing Angle(Deg.) | 140(H)/140(V) |
| Brightness(nits) | 1200 |
| Grey Level(bit) | 16 |
| Refresh Rate(Hz) | 1920 |
| Panel Size(mm) | 488(W)×488(H) |
| Panel Size(inch) | 19.21(W)×19.21(H) |
| Panel Resolution(pixels) | 128×128 |
| Panel Material | Die-casting Aluminum |
| Panel Weight(kg) | 11 |
| Module Size(mm) | 244(W)×244(H) |
| Module Size(inch) | 9.61(W)×9.61(H) |
| Module Resolution(pixels) | 64×64 |
| Protection Grade(Front/Rear) | IP30 |
| Serviceability | Rear |
| Voltage(V)) | AC110/220 |
| Avg.Power Consumption(W/㎡) | 250 |
| Max.Power Consumption(W/㎡) | 750 |
| Brightness Adjustment | Manual/Auto/Programmable |
| Operating Temp/Humidity(℃/%RH) | -10~+50/10~95 |
| Storage Temp/Humidity(℃/%RH) | -40~+85/10~95 |
| Lifetime(hours) | ≥50000(Nomal Temp) |
| Compliant Standard | CE,FCC,RoHS |
