MiTex

Intel® Ivy Bridge 1047UE Až 16 GB DDR3 SO-DIMM VGA, DVI, HDMI, LVDS, 2 x Gb Ethernet, 2 x Mini PCIe, 1 x SIM card socket, 9 x USB, 6 x COM

PRODUKT JIŽ NENÍ URČEN K PRODEJI

Vlastnosti

•	Embedded Intel® Ivy Bridge 1047 UE 1.4GHz, i3, i7 CPU +Intel Pather Point (PCH) HM76
•	DDR3 SO-DIMM Socket x 2
•	Multi Independent display: VGA, DVI & HDMI
•	2 x Intel GbE LAN, 9 x USB, Line-out, Mic-in, 4~6 x COM
•	2 x Mini PCIe ;1 x SIM card socket

E-617A: 4 Port PoE PCI Express Communication Card

•	PCI Express® x 1 Compliant
•	Intel® Gbe Mac Controller
•	Supports PoE(Power over Ethernet),IEEE 802.3af compliant
•	Powered Device (PD) auto detection and classification
•	Supports IEEE 802.3u Auto –Negotiation
•	Supports 12V DC input power boost up to 15.4 watts at 48V DC per PoE port

ODEL		CI847AW
System Dimension (W x Dx H)		266W x 204D x 86.5H mm
Weight(Incl.M/B)		2.8 Kg
CPU		Intel Ivy Bridge Celeron 1047 UE 1.4 Ghz; i3, i7
Chipset		Intel Panther Point (PCH) HM76
System Memory		Support DDR3 1066/1333 MT/s SO-DIMM x 2 ; Max up to 16 GB
SSD storage	CF (CFast)	CFast (Optional)
	mSATA	Yes
	On Board SSD	Optional
HDD Space		2.5" HDD (2 x SATA ports 3.0 + 2 x SATA ports 2.0)
VGA		Yes
DVI / HDMI		DVI / HDMI
USB		Built-in 4 x USB,expand up to 9 x USB (USB 3.0 x 2+ USB 2.0 x 7)
PS2/ KB/MS		Optional
COM		Built-in 4 x COM, expand up to 6 x COM
PCI / PCIe		2 (Optional)
Mini PCIe		2
SIM Card Holder		2
Ethernet		Intel GbE x 2
Min-in/Line-out		Yes
GPIO		8 DI/DO (Optional)
Power input		DC+12V; Wide Range DC in+9~36V (Option)
Expansion		PoE LANs, GPS, IEEE1394, 3G, Bluetooth, WI-FI, I/O
Operating Temp		0~45°C for HDD, -20°C~60°C for mSATA / 2.5" SSD HDD
Operating Humidity		5 ~ 95%@ 60 °C, non-condensing
