7" SHARK
7" SHARK Bezel-free Fanless Panel PC
Základní informace
Dostupné základní desky:
| MB Type | CPU onboard | Memory support | USB | Serial | LAN | Resolution | Exp. | Storage support |
| 2I268C-DH26 | N2600 1.6GHz | 2GB onboard | 2 | 0 | 1 x Giga | 1024 x 600 | 2 mini-card | mSATA |
| 2I385CW-I44 | E3845 1.91GHz | 4GB onboard | 2 | 1 | 2 x Giga | 1024 x 600 | 2 mini-card | mSATA |
Specifikace
| MODEL | 7" + 2I268C | |
| Dimension (mm) | 184.7W x 40H x 122.5D mm | |
| Weight | 2 Kg | |
| Hard drive | N/A | |
| LCD brand | CPT | |
| LCD size | 7 inch, 16:9 | |
| Max Resolution | WSVGA 1024 × 600 | |
| Luminance (cd/m2) | 375 | |
| Contrast Ratio | 400:1 | |
| Viewing Angle (H-V) | 140(H)-110(V) | |
| Backlight | LED | |
| Touch Screen | Resistive touch screen | |
| MB | 2I268C-DVI | |
| CPU | Intel Cedarview-M N2600/N2800 1.6/1.86 GHz | |
| Chipset | Intel Cedarview-M + NM 10 | |
| Memory | Type / Capacity | DDR3 800 MT/s for N2600, Max up to 2GB
DDR3 1066 MT/s for N2800, Max up to 4GB |
| SO-DIMM | N/A | |
| On board memory | 2GB | |
| SSD Storage | CF (CFast) | N/A |
| mSATA | Yes (Half Size) | |
| On Board SSD | Optional | |
| VGA | Optional | |
| DVI / HDMI | DVI | |
| USB | 2 | |
| COM | Optional | |
| MiniPCIe | 2 | |
| SIM Card Holder | Realtek GbE x 1 | |
| GPIO | 4DI / 4DO (Optional) | |
| Ethernet | Realtek GbE x 1 | |
| Audio | Line-out | |
| Power Input | DC IN +12V | |
| Battery | option (3500 mAh) | |
| Mounting | VESA 75 | |
| Panel frame water proof | IP65 | |
| Optional MB | 2I385CW | |
| Expansion | GPS, 3G/4G, Bluetooth, WI-FI, I/O | |
| Operating Temp. | -20°C~60°C for mSATA | |
| Operating Humidity | 5~90% @ 39°C, non-condensing | |
