eGFX Home Read Station

Flexible remote radiology reading solution

Petr Chalupa

Petr Chalupa

Odolné PC, Military, TEMPEST, Doprava +420 251 614 073

Základní informace

As a radiologist, with the eGFX Home Read Station you're all set to start reading at home. It's a flexible and mobile radiology workstation solution that assures dependable image quality and consistent workflow wherever and whenever you are working. Using an eGFX station connected over ThunderboltTM 3, you can enjoy the same imaging performance, workflow productivity and tools at home as in the hospital.

Compatible with Barco displays systems and validated mobile workstations, you'll lose no time and effort in configuring and supporting remote reading stations. With QAWeb Enterprise, quality and compliance of all workstations can be managed remotely, so software updates and security scans can be executed easily.

Remote reading allows radiologists to work more efficiently, ensures optimal working conditions and enables a flexible work schedule. On-call, weekend and late-evening duties, for example, can be performed at home instead of at the hospital. With the millennial generation and digital natives entering the workforce, home reading is becoming a standard benefit in radiology hiring.


Power consumption 240W
Operating system Windows 10 (64-bit)
Platforms Intel® and AMD architectures
Power Connector None
Graphics accelerator AMD Radeon Pro™
Display memory 4GB DDR5
Memory interface 128-bit
Memory bandwidth 92 GB/s
Pixel depth 32-bit pixels (10-bit grayscale and 30-bit color)
Electrical standard DisplayPort (DP) v1.4
Direct3D hardware support Microsoft® DirectX v12, Vulkan® 1.1, Shader Model 5.1
OpenGL hardware support OpenGL 4.5
Connectors (1x) DisplayPort 1.4 (2x) Mini-DisplayPort 1.4
Environmental 0° to 55°C
Connectivity DisplayPort to Single-link DVI adapter available separately
2x USB 3.0 ports on the front for added connectivity
RJ 45 ethernet Gigabit LAN connection for high speed network connectivity, located on the back side of the enclosure
Bandwidth Up to 40Gbps
Cooling Perforated design and internal fans allow for ample cooling of the graphics card
Cover Aluminum design for lightweight performance
Dimensions 8.5” x 6” x 2.75”
