TransForm N Output Node with JP2K support
Output component for networked visualization. Barco’s TransForm N Output Node with JP2K Support is a powerful PC-based network graphics processor. It is used in networked visualization environments and can display encoded streams coming from a Gbit Ethern
PRODUKT JIŽ NENÍ URČEN K PRODEJI
Klíčové prvky
- Universal Display Agent
- High-end 3D graphics acceleration
- Universal Decoding Blocks
- Universal IP streaming video decoding
- JP2K hardware accelerated decoding
- Frame lock between multiple output nodes
- Up to 8 x 1920x1200 displays
- Redundant network interface
- Redundant power supply
- Intel™ processor
Specifikace
| Form factor | 4U housing for 19" rack |
| Output | Up to 8 HD displays |
| Input | 24 V-Cores (see V-Core Table) |
| Platforms | NGP-124 |
| Redundancy | Power supply , 2x 1Gb LAN |
| Power Supply | Mains 100-240V, 50|60Hz |
| Power consumption | 400W |
| Dimensions | 400 x 177 x 566 mm (17.32 x 6.97 x 22.28 inch) |
| Operating temperature | 0°C–35°C |
| Operating humidity | max. 80% (non-condensing) |
