OverView IVD5521

55" jednolitá LCD videostěna - Vysoký jas - Velmi spolehlivý - Kalibrace Sense a automatická - Dálkový redundantní napájecí zdroj (volitelný) - Optimalizováno pro obsah s bílým pozadím


Základní informace

Barco's OverView IVD5521 is a high-performance, high level brightness (700 cd/m² typical) 55" LCD-panel, dedicated for use in tiled video wall applications. With an extremely narrow bezel of only 3.5 mm (0.14"), excellent colors, uniformity and a wide viewing angle, the OverView IVD5521 takes the visual performance of LCD video walls to a new level.

Its best in class temperature sensor controlled heat management system, uses ultra low noise fans to ensure optimal cooling at all time, maximizing the backlight's lifetime. Additional innovations and low power consumption ensure this panel delivers maximal image quality at a minimal TCO.
Saving costs with automatic color and brightness calibration

All the different screens in a tiled LCD video wall need to be perfectly balanced in terms of colors and brightness, so regular calibration is essential. As the first and only manufacturer, Barco now introduces its Sense X automatic color and brightness calibration system, that lets you calibrate the complete wall within minutes, without any external sensor or manual intervention.
External power supply without performance loss

As an option, you can choose an external power supply. This allows to greatly reduce the maintenance costs, as there is no need for an expensive specialized technician. Everybody with a screwdriver can maintain and replace the equipment. Unlike competing models there is no performance impact for longer cables, so the external power supply can be positioned up to 100 meter from the video wall without any loss in image quality or brightness.


LCD technology IPS
Screen haze 44%
Resolution Full HD (1920 x 1080)
Backlight Direct LED
Aspect ratio 16:09
Pixel density 40 dpi
Refresh rate 60 Hz
Luminance 700 cd/m2 (typ.)
Contrast 1400:1 (typ.)
500000:1 (dynamic)
Viewing angle H 178° | V 178°
White point 10,000 K
Color depth 10 bits
Calibration Sense X automatic color and brightness calibration
Precision Internal 10 bit processing
Backlight lifetime 60,000 h (typ)
MTBF 100,000 h (half brightness)
Cooling Ultra low noise fans
Dimensions 1213.5 x 684.3 x 99.0 mm | 47.8" x 26.8" 3.9"
Active screen diagonal 54.6" (1388 mm)
Active screen area 1210 mm x 680 mm | 47.63" x 26.79"
Weight 29.2 kg | 64.4 lbs
Bezel width 3.5 mm | 0.14"
DVI 2 inputs
Display port 1 input/output
HDMI 1 input
USB 1 input (USB 2.0)
Ethernet port 2
OPS Open Pluggable Specification Yes
Remote control External dongle with approx. 1m 3.5mm Stereo Male to IR Receiver
AC input voltage 100-240 VAC, 50-60 Hz
Power consumption 300 W (typ) | 400 W (max)
Heat dissipation Integrated power supply: 1024 BTU/h (typ) | 1365 BTU/h (max)
External power supply: TBD
EnergyStar Full wall EnergyStar
