Odolný počítač / server s výškou 2U pro zabudování do 19'' racku
Základní informace
Aqeri 9102 is a rugged 19" slim line computer for use in harsh environments. Its’ small dimensions and front accessibility makes it suitable for space critical applications. The chassis is fully sealed for protection against dust and corrosive elements. Cooling is provided by a heat exchanger cooling system. A fully aluminum construction stands for low radiation and high noise immunity (according to MIL-STD-461D). The rugged design, including a separately hinged cradle for mass storage units, gives protection against shock and vibration. An internal heating and climate control system makes the unit usable in extremely low-temperature environments. Based on COTS technology, the computer can be configured for various server and workstation applications
Specifikace
| TECHNICAL SPECIFICATIONS | |
| Processor: | Intel® Core i7-620M 2.66GHz |
| Memory: | DDR3 up to 8GB |
| Operating system: | Optional, Windows, Linux |
| Storage: | Up to 2x 2,5" or 3,5" HDD/SSD drive and 1x DVD-RW |
| RAID: | Optional 0/1 |
| I/O Interfaces: | |
| USB: | x2 |
| Gigabit Ethernet, Fibre Ethernet optional | x2 |
| VGA: | x1 |
| RS2321x RS-232/422/485 | x1 |
| Graphics: | Intel® Gen 6.0 integrated Graphics Engine |
| Expansion: | Optional 1x 32bit PCI Audio |
| CONNECTORS | |
| USB: | Hirose |
| Ethernet: | RJ45 and/or SC |
| VGA: | HD-DSUB |
| RS232: | DSUB |
| DC in: | MS310F 10SL-3S |
| PHYSICAL CHARACTERISTICS | |
| Dimensions: | 440 x 88 x 400mm (WxHxD) |
| Weight: | 12kg |
| Color: | Green, other optional |
| ELECTRICAL SPECIFICATIONS | |
| Power requirements: | 28VDC (18-36VDC, safe start Min 21VDC, Max 33VDC) |
| Power consumption: | 68W at 28VDC (excluding heaters) |
| ENVIRONMENTAL CHARACTERISTICS | |
| Designed to fulfill (other standards on request): | MIL-STD-461E MIL-STD-1275B MIL-STD-810G European CE |
| TEMPEST SDIP-27 Level A, B, C | Option |
| Temperature Operating: | -20°C to +55°C |
| Vibration Operating (depending on configuration): | 10-500Hz 1,04g rms |
| Shock Operating (depending on configuration): | 15g, 11ms, ½ sine wave |
| Humidity: | 5% to 95% non condesing |
| Altitude Operating: | 3000m |
