AM4002
Processor AdvancedMC module with Intel Pentium M AMC Processor Module, single-width, mid-size/full-size Intel Pentium M, scalable up to 1.8 GHz Max 4 GB DDR2 400 MHz memory Max 4 GB soldered Flash for embedded application code Flexible Gigabit and
PRODUKT JIŽ NENÍ URČEN K PRODEJI
Detail
High performance Processor AMC
Versatility of AdvancedMC technology
The AM4002 is a highly integrated AMC processor module dedicated to support a wide range of telecom applications demanding maximum I/O throughput. Field replacable and extremely scalable, the AM4002 incorporates a high performance Intel Pentium M processor and appropriate chipset, as well as, flexible Gigabit Ethernet and PCI-Express fabric interfaces. This provides TEMs with both superior processing power and increased design options for next generation network applications.
Vlastnosti
Versatility of AdvancedMC technology
The AM4002 is a highly integrated AMC processor module dedicated to support a wide range of telecom applications demanding maximum I/O throughput. Field replacable and extremely scalable, the AM4002 incorporates a high performance Intel Pentium M processor and appropriate chipset, as well as, flexible Gigabit Ethernet and PCI-Express fabric interfaces. This provides TEMs with both superior processing power and increased design options for next generation network applications.
Vlastnosti
| CPU | Intel® Pentium M®, 1.4 GHz or 1.8 GHz |
| DRAM | Up to 4 GByte registered DDR2 400 MHz with ECC |
| Chipset | Sever-class chipset Intel® E7320 & Intel® 6300ESB |
| Compliance | PICMG: AMC.0 / AMC.1 / AMC.2 / AMC.3; Support for IPMI Category |
| Connectivity | System Interconnect: 2x GbE, 1x PCI-Express x4, 2x SATA |
| CPU L2 Cache | 2 MByte |
| Flash | Up to 2 GByte CompactFlash (soldered) |
| Form Factor | Single width, full-size or mid-size |
| Front Side Bus | 400/533 MHz |
| Frontpanel | 1x USB 2.0 (via MiniUSB type 4/5), 1x COM (via D-Sub), 8 Control/Status LEDs |
| Graphics | - |
| Options | - |
