NI525A

Jednodeskový počítač s procesorem Intel Atom D525

Odolné PC, Military, TEMPEST, Doprava +420 251 614 073 pchalupa@nowatron.cz

Intel Atom D525 processor, 4-Port 802.3af PoE, 2 SATA, LVDS,
PCIe Mini Card, WDT/DIO, Touch Screen, 8USB, SIM Card Socket

MODEL	NI525A
CPU Type	Intel Atom D525 1.8 GHz ( Dual core processor )
MB Chipset	Intel Atom D525 + ICH8M ( 82801 HBM )
BIOS	Award BIOS
Graphics	Intel Luna Pier Refresh Pineview-D Integrated Graphics Engine
LVDS	Data format of 18 bits
System Memory	1 x DDR3 SO-DIMM socket ( max. 4GB )
NAND Flash Memory	CF Card Type 2 socket for ATA interface
SATA	2 x SATA ports + 2 x eSATA ports ( option )
Audio	Intel HD Audio Specification Rev. 1.0 Compliant
LAN	3 x lntel 82574L 10 / 100 / 1000Mbps
PoE LAN	4-Port from Realtek Gigabit Switch controller
PoE Controller	Microsemi 4-Port 802.3af PSE Manager
IO Function	1 x RS232 / 422 / 485 + 1 x RS232 or 485 ( option )
USB	8 x USB 2.0 ( 4 external + 4 internal )
Touch Screen	USB interface Touch screen controller Support 4- , 5- , 8- wire Analog Resistive Touch screen USB 1.1 full speed sample rate maximum of 300 point / sec Resolution 2048 x 2048
DIO & WDT	Hardware digital Input & Output, 8 x DI / 8 x DO Hardware Watch Dog Timer, 0~255 sec programmable
Expansion Interface	1 x PCIe mini card for PCIe & USB interface with 3G SIM card socket
Power	On board DC +48V ± 5% convert to +3.3V / +5V / +12V for system
Dimension	200 x150 mm
Operation Temperature	0 ~ 60 °C
Operation Humidity	5 ~ 95% @ 60 °C, non-condensing
Expansion	GPS, IEEE1394, 3G, Bluetooth, WI-FI, I/O
Chassis	TWISTER
