3V900C
Jednodeskový počítač s procesorem VIA Nano E-series; Nano 1GHz Single core
Specifikace
| MODEL | 3V900C |
| CPU Type | VIA Nano E-series processor Nano 1GHz Single core |
| Front Side Bus | 800 MHz |
| MB Chipset | VIA VX900 |
| BIOS | Award BIOS |
| Graphics | Integrated with VIA VX900 Shared system memory up to 512MB MPEG-2/MPEG-4/VC1/WMV/H.264 decoding mode |
| LVDS 1 | Data format of 18/24 bits Support panel resolutions up to 1366 x 768 |
| LVDS 2 | Data format of 18/24 bits or 36/48 bits Support panel resolutions up to 1920 x 1080 |
| System Memory | 1 x DDR3 1066MHz SDRAM (max. 4GB) |
| SATA | SATA and 1 x CFast Card Type I/II or 2 x SATA (option) |
| HDMI | Compatible with HDMI V 1.2 |
| DISPALY Port (option) | Compatible with Display port 1.1a |
| Audio | HD Audio codec; Two channel SOUND Support Line-out / Mic-in / Line-in |
| LAN | 1 x Realtek RLT 8111DL 10/100/1000 Mbps (optional Intel 82574L GbE) |
| IO Function | 5 x RS232 or RS485 (option) + 1 x RS485 / 422 Support PS/2 keyboard & mouse |
| USB | 7 x USB 2.0 (2 external + 5 internal) |
| Touch Screen | USB interface Touch screen controller Support 4-, 5-, 8- wire Analog Resistive touch screen USB 1.1 full speed sample rate maximum of 300 point per second |
| DIO & WDT | Hardware digital Input & Output, 8 x DI / 8 x DO Hardware Watch Dog Timer, 0~255 sec programmable |
| Audio Amplifier | Two channels Audio Amplifier 6W/CH Class-D operation into an 8-Ω Load from a 12-V Supply |
| Expansion Interface | 2 x PCIe mini card for PCIe & USB interface optional 3G SIM card socket |
| Power | On board DC +12V ± 5% convert to +3.3V / +5V / +12V for system |
| Dimension | 145 x 102 mm (3.5 inch) |
| Operation Temperature | 0 ~ 60 °C |
| Operation Humidity | 5 ~ 95% @ 60 °C, non-condensing |
| Expansion | GPS, IEEE1394, 3G, Bluetooth, WI-FI, I/O |
| Chassis | CUBE, BRIK 6COM |
